New Jersey Overweight Permit Cost: Worked Examples
How New Jersey prices an overweight or oversize permit, worked through three moves, plus the two rules that void the permit after you have paid.
By Evan Reid, Founder of Haul Handbook · Updated Jul 30, 2026
New Jersey does not look an oversize fee up in a table. It builds the number line by line, from a base fee, a per foot charge on width, a second per foot charge on length, a per ton charge on weight, and a transaction charge that lands on the total. Two loads that look identical on a lowboy can price differently because one of them is three feet longer. Every figure this guide stacks renders with its source on the New Jersey oversize and overweight permits page. To see which states call your load oversize in the first place, run it through the oversize permit cost estimator.
How New Jersey builds the number
N.J.A.C. 13:18-1.6 sets the schedule out in five parts, and the order they attach in matters:
- One base fee or the other. A single-trip permit for a vehicle that is oversize only, or overweight only, starts at $10.00. A vehicle that is both starts at $20.00, and the rule is explicit that the additional oversize and overweight fees then apply on top of that higher base rather than instead of it.
- Width, measured from 14 feet. $1.00 for each foot or fractional portion of width over 14 feet, load included. A fraction counts as a whole foot, so a load at 15 feet 6 inches is charged two of them, not one and a half.
- Length, measured from 63 feet. $1.00 for each foot or fractional portion by which the combination exceeds 63 feet. Read 63 feet as a fee threshold, not a legal limit: the legal length ceilings live in N.J.S.A. 39:3-84 and vary by configuration, and they render on the state permits page. Once a permitted move is long, this line is charged by the foot and does not stop.
- A separate threshold for house-type trailers. $1.00 for each foot or fractional portion over 70 feet overall for a house-type trailer or semitrailer and its towing vehicle. Manufactured housing is measured against its own line rather than the general one.
- Weight, per 2,000 pounds. $5.00 for each 2,000 pounds or fractional portion by which the vehicle including load exceeds either the axle or the gross weight limits set in Title 39, whichever is greater. The count is not always taken from the gross figure, which is why a load that is heavy on one group can price above what its gross weight alone suggests.
- A transaction charge on every permit. $12.00 for each permit transaction, plus a service charge of 5 percent of the total permit fee. A single-trip permit for a vehicle that is both oversize and overweight is charged that transaction once, not twice.
The 5 percent lands on the transaction fee too
Two published totals settle how the service charge is computed, and quotes that miss this come out low. N.J.A.C. 13:18-1.6(e) and (f) waive every fee except the transaction charge for a government-owned or operated vehicle and for a single-trip permit issued to a combination using a Code 23 registered trailer. NJDOT's Commercial Vehicle Size and Weight Guidebook prints what that fee-free permit actually costs: $12.60.
The annual permit gives the second data point. Its base fee is $100.00, and the same guidebook prints the charge as $117.60. Both totals reconcile the same way: the service charge is 5 percent of the base fees and the transaction fee added together, not 5 percent of the base fees alone. Add the transaction fee first, then apply the 5 percent to the pair, and the number you hand a customer matches the one the permit system bills.
Worked example 1: sixteen feet wide, legal weight
An excavator that measures 16 feet wide on the trailer, at legal height, legal length and legal registered weight, is oversize only. None of the weight side of the schedule touches it.
The permit starts at $10.00. Width is two feet over the 14 foot line, so two width increments of
$1.00attach, and a load at 15 feet 6 inches would attach the same two because the rule charges every foot or fractional portion. Then
$12.00and the 5 percent service charge close the transaction, and that is the whole permit.
The permit is the cheap part of this move. Over 14 feet wide, N.J.A.C. 13:18-1.12(a) requires one escort vehicle, which precedes the load on a highway with fewer than four traffic lanes and follows it on a highway with four or more. New Jersey assigns only private escorts, sets no escort certification requirement and puts no limit on the size or type of escort vehicle, so the carrier books and pays for that escort itself. The oversize permit is also not valid between sunset and sunrise, and not valid at all on New Year's Day, Memorial Day and the Friday before it, Independence Day, Labor Day and the Friday before it, Thanksgiving and the Wednesday before it, or Christmas Day. On a wide New Jersey move the calendar sets the delivery date long before the fee does.
Worked example 2: heavy, and inside every dimensional limit
Now take a transformer riding at 92,000 pounds gross on a trailer that is legal in every dimension. New Jersey's statutory gross weight limit is 80,000 pounds, so the load runs 12,000 pounds over it, and the single axle and tandem axle ceilings in N.J.S.A. 39:3-84 have to be checked separately because the fee counts from whichever limit the load exceeds by more.
This one is overweight only, so it starts at
$10.00as well. The excess weight line is
$5.00for each 2,000 pounds or fractional portion over the limit, and on this load six of those increments attach. Then
$12.00and the 5 percent close it out, exactly as on the wide move. Being overweight rather than oversize also buys back the calendar: the night and holiday bars sit in N.J.A.C. 13:18-1.11, which governs oversize permits, so a permitted overweight load inside legal dimensions is not held to them.
Then comes the rule that voids the permit. N.J.A.C. 13:18-1.10(a)1 says an overweight permit is not valid for a vehicle registered, or required to be registered, in New Jersey unless that vehicle is already registered in the state at the maximum registration weight allowed under N.J.S.A. 39:3-20. A carrier that registered light to hold down the commercial registration fee cannot buy its way over the limit with a permit; the registration has to be fixed first. The same section voids the permit when the gross weight including load puts more than 800 pounds per inch of tire width on the wheels, or when the load is distributed so as to put more than that on any one wheel. Both are checked at the roadside rather than at the counter. The apportioned side of New Jersey registration sits on the New Jersey IRP registration page.
Worked example 3: wide, long and heavy on one permit
A bridge girder exercises the whole schedule at once. Call it 15 feet wide, 96 feet from the front bumper to the rear of the load, and 104,000 pounds gross. That is oversize and overweight together, which changes the base and switches on both sets of add-ons.
The base is
$20.00rather than $10.00. Width is one foot over the line, so one increment of
$1.00attaches. Length is thirty-three feet over the 63 foot fee threshold, so thirty-three increments of
$1.00attach, which is the part carriers from flat-fee states never see coming.
The weight line is counted separately again.
$5.00attaches for each 2,000 pounds or fractional portion over the greater of the axle and gross excesses, and this load carries twelve of those increments. One transaction charge covers all of it: N.J.A.C. 13:18-1.6(d) bills the transaction fee and the 5 percent once on a single-trip permit issued to a vehicle that is both oversize and overweight, so the doubled base does not drag a doubled transaction along with it.
Escorts run on their own thresholds, and this is where the two schedules diverge. Width over 14 feet buys one escort vehicle and width over 16 feet buys two. Length buys nothing until 100 feet, with a second escort at 120 feet. The girder above is charged for thirty-three feet of length and picks up no length escort at all, because 96 feet is inside the escort threshold and well outside the fee threshold. Its one escort comes from the width band instead. Quote escorts from N.J.A.C. 13:18-1.12 and the fee from 13:18-1.6, and never one from the other.
If the move has to run after dark, the Chief Administrator can waive the nighttime and holiday restrictions on a request filed with the permit application, and NJDOT's guidebook states flatly that three escort vehicles are required under that waiver. The rule text is written as an increment: N.J.A.C. 13:18-1.12(c) requires one additional escort on top of whatever the width and length bands already called for, so a load sitting in the one escort band reads as two on the face of the rule. Plan on three and confirm the count printed on the permit, which is where NJDOT states the requirement for the specific move.
There is no superload class, there is a route review
Most states publish a weight or dimension line above which a load becomes a superload with its own fee and its own review clock. New Jersey publishes none. SUPERLOAD is the name of the NJDOT online permitting system reached through nj.gotpermits.com, not a load category, and the Superload Program issues ordinary oversize and overweight permits alongside the annual container permit.
What replaces the threshold is a structural review of the route. A single-trip application is rejected where the load and axle configuration overstress a structure on the proposed route, and the rejection names the structures that failed. The NJDOT Bureau of Structural Engineering helps the applicant pick an acceptable alternative. That is a schedule risk rather than a fee risk. The permit costs the same on the second route, but the second route can be longer, and a single-trip permit is valid five days, with a one-day extension available only for hazardous road conditions or a vehicle breakdown and only if the request reaches the Commission before the permit expires.
The one annual permit New Jersey sells
There is exactly one multiple-trip permit in the schedule, and it exists for the port. The annual ocean borne containerized cargo permit covers one tractor semitrailer combination hauling sealed containers of the type used in international ocean-going commerce, bearing a United States Customs, other government agency, or shipper seal, for a period not exceeding 365 days. Its base fee is
$100.00before the transaction charge.
It is a weight permit, not a size permit, and the ceilings are tight. Combined gross vehicle weight including the load cannot exceed 90,000 pounds, tandem axle weight cannot exceed 38,000 pounds, and a tri-axle trailer configuration cannot exceed 56,400 pounds. Moves have to be of legal dimension; the permit does nothing for an oversize or overdimensional load. The original permit carrying the raised State seal has to be in the vehicle, photocopies are not accepted, and travel is barred on the structures the permit identifies as restricted. Renewal is the holder's job, because the Commission does not mail renewal forms, and a combination above those weights goes back to buying single-trip permits.
The permit is not valid on the toll roads without a second approval
The line items in New Jersey are small numbers, which makes the voiding rules the expensive part of the file. The registration rule in example 2 is one of them. The toll roads are the other.
N.J.A.C. 13:18-1.9(a)2 says no permit is valid on any toll road without the express approval of the tolling authority, and it names them: the South Jersey Transportation Authority for the Atlantic City Expressway, and the New Jersey Turnpike Authority for the New Jersey Turnpike and the Garden State Parkway. NJDOT does not issue on their behalf. A single-trip application has to state where the vehicle enters and leaves the state highway system, the Interstates, the Turnpike, the Parkway south of Exit 105 and the Expressway included, so the route is declared up front and any toll road on it is a separate approval to chase before the wheels turn.
Two other invalidity rules travel with every permitted move. An oversize permit is not valid on any highway where the clear space left for passing traffic, roadway and improved shoulder together, is less than ten feet, and it is not valid when daylight visibility drops below 500 feet or when hazardous road conditions exist. The Commission also reserves the right in N.J.A.C. 13:18-1.4 to name the route, the speed and the exact day and hour of travel, and those restrictions are printed on the individual permit rather than published as a statewide curfew list. Read the permit.
What to check before quoting
Measure width against 14 feet and combination length against 63 feet first, because those are the two lines that repeat per foot. Count the weight increments from the greater of the axle excess and the gross excess rather than from the gross figure out of habit. Add the transaction fee, then apply the 5 percent to the whole thing including that fee. Ask whether the route touches the Turnpike, the Parkway or the Atlantic City Expressway and clear it with the tolling authority separately. Check the registration weight on file before selling an overweight move at all. And file the liability coverage: N.J.A.C. 13:18-1.7 says an application is not accepted without proof of it, and the required limits render with their source on the New Jersey oversize and overweight permits page. Compare the result against the same move elsewhere on the oversize permit costs by state table, and see the rest of the credential stack at New Jersey trucking permits.
FAQ
How is a New Jersey oversize or overweight permit priced?
By arithmetic, not by a tier lookup. N.J.A.C. 13:18-1.6 sets one base fee for a vehicle that is oversize only or overweight only and a higher one for a vehicle that is both, then adds a per foot charge on width over 14 feet, a per foot charge on combination length over 63 feet, and a per 2,000 pound charge on weight over the limit. Every transaction then adds a flat fee plus a service charge of 5 percent. The current figures render with their source on the state permits page.
Is a New Jersey permit valid on the Turnpike or the Garden State Parkway?
Not on its own. N.J.A.C. 13:18-1.9(a)2 says no permit is valid on any toll road without the express approval of the tolling authority, and it names the New Jersey Turnpike Authority for the Turnpike and the Garden State Parkway and the South Jersey Transportation Authority for the Atlantic City Expressway. Clear the toll road separately before the wheels turn.
Why would a New Jersey overweight permit be void?
Two reasons catch carriers most often. An overweight permit is not valid for a vehicle registered, or required to be registered, in New Jersey unless that vehicle is already registered in the state at the maximum registration weight allowed under N.J.S.A. 39:3-20, and it is not valid when the load puts more than 800 pounds per inch of tire width on the wheels. Paying for the permit does not cure either one.
